Consew 339RBATCWL(N) Double Needle Heavy Duty Compound Walking Foot Sewing Machine with Table and Servo Motor

No reviews yet Write a Review
Market Price: $7,197.00
$6,298.00
Save $899.00 per unit
SKU:
339RBATCWL(N)#
Condition:
New
Shipping:
  • Flexible financing available through Synchrony
Need a Part? Browse our +500,000 Sewing Machine Parts Catalog!

Consew 339RBATCWL(N) Double Needle Heavy Duty Compound Walking Foot Sewing Machine with Table and Servo Motor

Market Price: $7,197.00
$6,298.00
Save $899.00 per unit

Consew 339RBATCWL(N) Double Needle Heavy Duty Compound Walking Foot Sewing Machine with Table and Servo Motor

Market Price: $7,197.00
$6,298.00
Save $899.00 per unit

Consew 339RBATCWL(N) Double Needle Heavy Duty Compound Walking Foot Sewing Machine with Table and Servo Motor

The Consew 339RBATCWL(N) is a double needle, heavy-duty sewing machine designed for precision and efficiency. It features a drop feed and needle feed system (compound feed) along with alternating presser feet. The lockstitch machine is equipped with a Centra-lube semi-automatic lubrication system and offers programmable functions for enhanced versatility. Additional features include automatic backtacking, reverse feed, thread trimming, needle up/down functionality, a pneumatic foot lift, and a safety clutch.

Consew 339RBATCWL(N) Double Needle Heavy Duty Compound Walking Foot Sewing Machine with Table and Servo Motor Brochure Page 1Consew 339RBATCWL(N) Double Needle Heavy Duty Compound Walking Foot Sewing Machine with Table and Servo Motor Brochure Page 2

MACHINE APPLICATIONS:

  • Automobile upholstery
  • Tarpaulins
  • Covers
  • Awnings
  • Tents
  • Umbrellas
  • Handbags
  • Luggage
  • Travelware accessories
  • Sports and camping equipment
  • Outdoor clothing

MACHINE FEATURES:

  • Pedal Operation: Precise control of the motor via foot pedal; forward pressure controls speed, and backward pressure controls reverse stitching speed.
  • Adjustable Pedal Pressure: Operator can adjust the spring position for desired foot pressure, ensuring fast and accurate start-stop actions with linear speed control.
  • Unblocked Hand Wheel: Freely movable hand wheel, even when stopped, for easy threading and adjustments.
  • Electronic Controls: Rugged servo-motor allows for precise control of motor actions and additional functions like trimming and foot lift.
  • Precise Needle Positioning: Specially designed servo-motor ensures precise needle positioning and stopping accuracy, reducing needle breakage.
  • Switching of Needle-Up/Down-Stop: Allows selection of needle-up or needle-down stop at seam end for convenience in continued sewing or work removal.
  • Auto Backtack Button: Conveniently located near the needle, a one-touch programmable backtacking function with push-button reverse and safety lockout adjustment.

MACHINE SPECIFICATIONS:

  • Number of Needles: 2 (Double)
  • Feeding Mechanism: Walking Foot
  • Workspace: Standard Workspace
  • Standard or Full Function: Auto Trimming, Backtack, Reverse
  • Speed, Max (S.P.M.): 3000
  • Stitch Length: 2 1/2" s.p.i. (10mm)
  • Work Space: 10" (258mm)
  • Needle: 135 x 17
  • Bobbin: Metal 15041, Pre-wound S or U
  • Bed Size: 7" x 18 7/8" (178mm x 477mm)
  • Stitch Type: 301
  • Needle Bar Stroke: 4 s.p.i. (8mm)
  • Standard Needle Spacing: 1/8" (3.2mm) - 1 1/2" (38.1mm)
  • Hook: 15040
  • Foot Lift: By Hand: 25/64" (10mm), By Knee: 1/2" (13mm), Electric: 1 5/16" (33mm)

Machine Warranty Protection

Besides any applicable warranties provided by the Original Manufacturer, Jacksew offers a standalone 90-day limited warranty on defects in materials and workmanship.

  • This warranty covers all the machine parts and labor but any shipping costs must be covered by the customer

  • Only applies under normal sewing conditions as prescribed for the machine

  • Consumable items are not covered (needles, bobbins, bobbin cases, springs, oil, and belts)

  • This warranty does not cover improper use or abuse under heavy use of machines

  • This warranty does not cover flood, fire, or other acts of nature

If there are any warranty issues that arise, we ask that you contact us immediately and let us know the details. In most cases, we can guide you with getting your machine in good sewing condition via phone, text or video chat.

If you need any parts that need to be replaced, we stock the majority of parts for immediate shipment. Some parts not in stock may have to be ordered from the manufacturer and may take 1 to 2 weeks for arrival.

If there is a critical issue that needs to be addressed and is out of scope of minor adjustments or repairs, we will ask you to send us the machine to our shop so we can have it repaired and have it back to good sewing condition. In most cases, we will only need the machine head shipped to us. Shipping charges - both inbound and outbound - are the responsibility of the customer.

Warranty issues do not arise frequently because of our commitment to assemble, test and verify each machine we ship out to our customers. We will never send you a machine directly from the manufacturer in boxes without knowing that the machine will be ready to operate upon arrival.

DISCLAIMER: DUE TO THE HEAVY WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.

ANY DAMAGE OCCURRING DURING SHIPPING MUST BE CLAIMED TO THE FREIGHT CARRIER IMMEDIATELY. UPON REQUEST, JACKSEW WILL PROVIDE ASSISTANCE IN FILING A CLAIM ON YOUR BEHALF DURING SUCH AN EVENT. PLEASE NOTIFY US WITHIN 5 BUSINESS DAYS.
