Juki MEB-3200CSSDM Computer-Controlled Eyelet Buttonholing Sewing System Complete Unit

No reviews yet Write a Review
Market Price: $30,166.00
$28,256.00
Save $1,910.00 per unit
SKU:
MEB-3200CSSDM
Condition:
New
Shipping:
  • Flexible financing available through Synchrony
Need a Part? Browse our +500,000 Sewing Machine Parts Catalog!

Juki MEB-3200CSSDM Computer-Controlled Eyelet Buttonholing Sewing System Complete Unit

Market Price: $30,166.00
$28,256.00
Save $1,910.00 per unit

Juki MEB-3200CSSDM Computer-Controlled Eyelet Buttonholing Sewing System Complete Unit

Market Price: $30,166.00
$28,256.00
Save $1,910.00 per unit

Juki MEB-3200CSSDM Computer-Controlled Eyelet Buttonholing Sewing System Complete Unit

This computer-controlled eyelet buttonholing system represents the pinnacle of precision in industrial buttonhole production, combining advanced automation with exceptional accuracy. The machine features a sophisticated multi-cutting device that automatically performs multiple cloth-cutting operations, streamlining the entire buttonhole creation process. Equipped with a thread trimmer, it delivers consistent, professional-quality eyelet buttonholes with minimal operator intervention. This system is ideally suited for high-volume garment manufacturing, upholstery production, and other industrial applications where precise, repeatable buttonhole quality is essential.

MACHINE SPECIFICATIONS:

  • Machine Head: JUKI MEB-3200CSSDM (Buttonhole machine with direct-drive motor and semi-sunken head)
  • Max Sewing Speed: 2,200 stitches per minute (sti/min)
  • Lift Of The Work Clamp Foot: Maximum 16 mm (0.63")
  • Stitch System: 1-needle, double chainstitch (with gimp)
  • Needle: DO×558
  • Stitch Length: 10~38 mm (1.50") with thread trimmer
  • Needle Throwing Width: 2.0~3.2 mm (0.13")
  • Buttonhole Cutting Method: Cut-before, cut-after, or no cutting (selectable)
  • Lubrication: Automatic lubrication (looper and spreader: by oiler)
  • Lubricating Oil: JUKI New Defrix Oil No.2 (ISO VG32 equivalent)
  • Power Requirementconsumption: Single-/3-phase, 550VA
  • Compressed Air And Air Consumption: 0.5 MPa, 6 dm³/min (ANR), 8 cycles/min
  • Feed System: Intermittent feed by stepping motor
  • Multicutting Device: Standard
  • Thread Trimming: Automatic, adjustable thread trimming lengths
  • Dimensions: 1,060 mm (W) × 790 mm (D) × 1,230 mm (H)
  • Total Weight: 179 kg

THE ADVANTAGES OF A SERVO MOTOR:

  • Silent and use up to 90% less power than clutch motors
  • Infinitely adjustable speed control via foot pedal
  • Full power at all speeds, even at very low RPM
  • Instant start/stop with electronic braking
  • No parts to wear out or adjust
  • Lightweight, precise, and reliable

Machine Warranty Protection

Besides any applicable warranties provided by the Original Manufacturer, Jacksew offers a standalone 90-day limited warranty on defects in materials and workmanship.

  • This warranty covers all the machine parts and labor but any shipping costs must be covered by the customer

  • Only applies under normal sewing conditions as prescribed for the machine

  • Consumable items are not covered (needles, bobbins, bobbin cases, springs, oil, and belts)

  • This warranty does not cover improper use or abuse under heavy use of machines

  • This warranty does not cover flood, fire, or other acts of nature

If there are any warranty issues that arise, we ask that you contact us immediately and let us know the details. In most cases, we can guide you with getting your machine in good sewing condition via phone, text or video chat.

If you need any parts that need to be replaced, we stock the majority of parts for immediate shipment. Some parts not in stock may have to be ordered from the manufacturer and may take 1 to 2 weeks for arrival.

If there is a critical issue that needs to be addressed and is out of scope of minor adjustments or repairs, we will ask you to send us the machine to our shop so we can have it repaired and have it back to good sewing condition. In most cases, we will only need the machine head shipped to us. Shipping charges - both inbound and outbound - are the responsibility of the customer.

Warranty issues do not arise frequently because of our commitment to assemble, test and verify each machine we ship out to our customers. We will never send you a machine directly from the manufacturer in boxes without knowing that the machine will be ready to operate upon arrival.

DISCLAIMER: DUE TO THE HEAVY WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.

ANY DAMAGE OCCURRING DURING SHIPPING MUST BE CLAIMED TO THE FREIGHT CARRIER IMMEDIATELY. UPON REQUEST, JACKSEW WILL PROVIDE ASSISTANCE IN FILING A CLAIM ON YOUR BEHALF DURING SUCH AN EVENT. PLEASE NOTIFY US WITHIN 5 BUSINESS DAYS.
